(888) 312-8812 Login SignupCENTRIC 123.65009 C-Tek Standard Brake Drum
Tap to view 4 more
$12049
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Jun 15
CENTRIC 123.65009 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.65009 Specifications
Product Attributes
| Weight [cntrc] Kgs | 12.486 |
| Weight [cntrc] Lbs | 27.470 |
| Mounting Type [cntrc] | Behind the Hub |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 127.000 |
| Hub Hole / Register [cntrc] In | 5.000 |
| Height [cntrc] Mm | 125.730 |
| Height [cntrc] In | 4.950 |
| Friction Surface Width [cntrc] Mm | 78.994 |
| Friction Surface Width [cntrc] In | 3.110 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 307.100 MM |
| Maximum Brake Diameter (Discard) | 12.090 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 357.124 MM |
| Outside Diameter | 14.060 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.764 MM |
| Mounting Hole Diameter | 0.660 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890052708 |
CENTRIC 123.65009 Cross References
| Brand | Part Number |
|---|---|
| 101643, 1643, 1643DGS, 52-60151, 5260151, BD60151 | |
| N/A | 52-60151, 5260151, BD60151, E127-70-014, E128-70-014, 8790, BD8790, 63 92 730, D92 730, 8790C, 8790CG, 111643, D6TZ1113B, D8TZ1113B, D1UZ1126B, C6TZ1126B, 140012, PDR0012, 202900, 6401132, 440-1132, 832, AD8509, AD8509E, D5643, E8354, E12770014, E12870014, 87033, YH140012, 23043, X21507, BD1012, 1643, 1643DGS, 1643R, 101643, 78842009, 8842009, 7842009, 78-42009, 68190, 177198, 36554051 |
| PRONTO | BD8790 |
| RAYBESTOS | 1643, 1643R |
| WAGNER | BD60151 |
CENTRIC 123.65009 Fits Vehicles
- Ford E-300 Econoline (1969-1974)
- Ford E-200 Econoline (1973-1974)
- Ford P-350 (1967-1976)
- Ford F-350 (1979)
- Ford F-250 (1966-1979)
- Ford E-250 Econoline Club Wagon (1975-1980)
- Ford E-250 Econoline (1975-1980)
