(888) 312-8812 Login SignupCENTRIC 123.50001 C-Tek Standard Brake Drum
Tap to view 4 more
$64.43
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 123.50001 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.50001 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.727 |
| Weight [cntrc] Lbs | 17.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 42.930 |
| Hub Hole / Register [cntrc] In | 1.690 |
| Height [cntrc] Mm | 81.280 |
| Height [cntrc] In | 3.200 |
| Friction Surface Width [cntrc] Mm | 67.310 |
| Friction Surface Width [cntrc] In | 2.650 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 251.200 MM |
| Maximum Brake Diameter (Discard) | 9.890 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 280.000 MM |
| Outside Diameter | 11.024 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.200 MM |
| Mounting Hole Diameter | 0.480 IN |
| Nominal Drum Diameter | 248.900 MM |
| Nominal Drum Diameter | 9.800 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890094135 |
CENTRIC 123.50001 Cross References
| Brand | Part Number |
|---|---|
| 122.50001, F1EZ15K868E | |
| MAGMA PRODUCTS | PMU28008 |
| N/A | BD125634, 0832742, E127-10-006, E127-55-006, E128-55-006, 35062, BD35062, 123.50001, 35062G, 0K01126251B, 0K20126251A, 140674, PDR0674, 240432, 6401735, JBD356, E11103, E12710006, E12755006, 100982, 87658, 9658, 9658R, 9647DGS, 9658DGS, 8814022, 36521001 |
| PRONTO | BD35062 |
| RAYBESTOS | 9658, 9658R |
| WAGNER | BD125634 |
CENTRIC 123.50001 Fits Vehicles
- Kia Sportage (1995-1997)
