(888) 312-8812 Login SignupCENTRIC 123.44026 C-Tek Standard Brake Drum
Tap to view 4 more
$6699
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 23
CENTRIC 123.44026 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.44026 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 7.045 |
| Weight [cntrc] Lbs | 15.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 60.000 |
| Hub Hole / Register [cntrc] In | 2.362 |
| Height [cntrc] Mm | 73.400 |
| Height [cntrc] In | 2.890 |
| Friction Surface Width [cntrc] Mm | 62.700 |
| Friction Surface Width [cntrc] In | 2.469 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 303.200 MM |
| Outside Diameter | 11.937 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.400 MM |
| Mounting Hole Diameter | 0.567 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890051862 |
CENTRIC 123.44026 Cross References
| Brand | Part Number |
|---|---|
| 122.44026, F1EZ14B291D | |
| N/A | BD125059, 0832488, E127-49-031, E128-49-031, 35007, BD35007, 63 79 620, 4243128040, 35007G, 116303, 595, 100484, 140605, PDR0605, 207900, 6401670, 1043, DB4321, JBD361, JBD361E, D9438, E12749031, 87483, 21125, X21823, BD1578, 9483, 9483R, 9483DGS, 78-22024, 7822024, 8822024, 78822024, 36576025 |
| PRONTO | BD35007 |
| RAYBESTOS | 9483, 9483R |
| WAGNER | BD125059 |
CENTRIC 123.44026 Fits Vehicles
- Toyota Previa (1991-1997)
