Centric 123.40004 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.091 |
| Weight [cntrc] Lbs | 9.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 61.000 |
| Hub Hole / Register [cntrc] In | 2.402 |
| Height [cntrc] Mm | 61.500 |
| Height [cntrc] In | 2.421 |
| Friction Surface Width [cntrc] Mm | 39.000 |
| Friction Surface Width [cntrc] In | 1.535 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 237.000 MM |
| Outside Diameter | 9.331 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 11.750 MM |
| Mounting Hole Diameter | 0.463 IN |
| Nominal Drum Diameter | 200.000 MM |
| Nominal Drum Diameter | 7.874 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 805890140412 |
Part Interchanges
CENTRIC 123.40004 Cross Reference
We have 4 alternatives for the 123.40004 by CENTRIC:
Fits Vehicles
- Honda Wagovan (1984, 1986-1987)
- Honda Civic (1984-1987)
