(888) 312-8812 Login SignupCENTRIC 122.62036 Centric Premium Brake Drum
Tap to view 4 more
$6599
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
CENTRIC 122.62036 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.62036 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.455 |
| Weight [cntrc] Lbs | 12.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 110.000 |
| Bolt Circle Diameter [cntrc] In | 4.331 |
| Hub Hole / Register [cntrc] Mm | 65.278 |
| Hub Hole / Register [cntrc] In | 2.570 |
| Height [cntrc] Mm | 73.406 |
| Height [cntrc] In | 2.890 |
| Friction Surface Width [cntrc] Mm | 53.086 |
| Friction Surface Width [cntrc] In | 2.090 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 231.000 MM |
| Maximum Brake Diameter (Discard) | 9.094 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 270.764 MM |
| Outside Diameter | 10.660 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 13.970 MM |
| Mounting Hole Diameter | 0.550 IN |
| Nominal Drum Diameter | 217.500 MM |
| Nominal Drum Diameter | 8.560 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890601821 |
CENTRIC 122.62036 Cross References
| Brand | Part Number |
|---|---|
| 9771, BD126268, BD126350 | |
| N/A | BD126268, BD126350, E127-67-041, 18040001, YH140809, YH140817, 1408-24564, 80122, 80121, 21045G, 80122G, 15808572, 10379254, 10388690, 9771, 9774, 9774R, 1770931, 36547025, E12767041 |
| RAYBESTOS | 9771R, 9774R |
| Raybestos Brakes | 9771R |
| WAGNER | BD126268, BD180085, BD126350, BD126350E |
CENTRIC 122.62036 Fits Vehicles
- Chevrolet Cobalt (2007-2008)
- Pontiac G5 (2007-2008)
- Chevrolet HHR (2006-2008)
- Chevrolet Malibu (2004-2007)
