(888) 312-8812 Login SignupCENTRIC 122.51009 Centric Premium Brake Drum
Tap to view 4 more
$3949
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 16
CENTRIC 122.51009 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.51009 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 3.636 |
| Weight [cntrc] Lbs | 8.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 62.500 |
| Hub Hole / Register [cntrc] In | 2.461 |
| Height [cntrc] Mm | 63.200 |
| Height [cntrc] In | 2.488 |
| Friction Surface Width [cntrc] Mm | 44.110 |
| Friction Surface Width [cntrc] In | 1.737 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 182.000 MM |
| Maximum Brake Diameter (Discard) | 7.165 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 221.000 MM |
| Outside Diameter | 8.701 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.600 MM |
| Mounting Hole Diameter | 0.496 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890017295 |
CENTRIC 122.51009 Cross References
CENTRIC 122.51009 Fits Vehicles
- Hyundai Accent (2000-2002)
