(888) 312-8812 Login SignupMELLING ENGINE PRODUCTS M532 M532 Stock Replacement : Standard Volume, Standard Pressure, Aluminum Oil Pump With Gasket
Tap to view 1 more
$28299
Limited availability at this price!
In Stock
Get as soon as Friday, Nov 6
MELLING ENGINE PRODUCTS M532 Part Description
MELLING ENGINE PRODUCTS M532 Specifications
Product Attributes
| Title | Engine Oil Pump |
| Width | 16.0 IN |
| Width | 406.0 MM |
| Height | 10.13 IN |
| Height | 257.0 MM |
| Grade Type | Standard Replacement |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 16 |
| Housing Material | Aluminum |
| Drive Type | Crankshaft |
| Oil Pump Type | Rotary |
| Mounting Hole Diameter | 0.25 IN |
| Mounting Hole Diameter | 6.0 MM |
| Adjustable Bypass Pressure | No |
| Alternate Pressure Springs Included | No |
| Oil Pump Pressure Type | Standard Pressure |
| Oil Pump Volume Type | Standard Volume |
| Gears Included | Not Applicable |
| Pickup Screen Included | No |
| Intermediate Shaft Included | No |
| Inlet Size (in) | 1.125 |
| Inlet Size (mm) | 28.00 |
| Cover Material | Aluminum |
| Bolts Included | No |
| Bushing Included | No |
| Cotter Pin Included | No |
| Finish | Rust Preventative |
| Governor Spinner Included | No |
| Guide Included | No |
| Nylon Bushing Included | No |
| O-Ring Included | No |
| Pump Cover Included | Yes |
| Shaft Material | Not Applicable |
| Timing Cover Included | Yes |
| Washers Included | No |
| Spacer Included | No |
| Pickup Tube Diameter | 28.00 MM |
| Drive Shaft Included | No |
| Pickup Tube Diameter | 1.125 IN |
| Rotor Material | Powdered Metal |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309060 |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | TW |
| UPC | 00729295105244 |
MELLING ENGINE PRODUCTS M532 Cross References
| Brand | Part Number |
|---|---|
| Honda | 15100-R1A-A01, 15100-RNA-A02, 15100-RNC-T01 |
| ITM Engine Components | 057-1550 |
| MELLING ENGINE PRODUCTS | M532 |
| N/A | M532, OP246B, OP246 |
| Safety Auto Parts Corp | P012-M111, P012-M126 |
| Topline | OPH45 |
MELLING ENGINE PRODUCTS M532 Fits Vehicles
- Honda Civic (2006-2015)
- Honda HR-V (2016-2022)
