CENTRIC 122.44036 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.44036 Specifications
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 4.773 |
| Weight [cntrc] Lbs | 10.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 62.000 |
| Hub Hole / Register [cntrc] In | 2.441 |
| Height [cntrc] Mm | 64.000 |
| Height [cntrc] In | 2.520 |
| Friction Surface Width [cntrc] Mm | 55.000 |
| Friction Surface Width [cntrc] In | 2.165 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 230.600 MM |
| Maximum Brake Diameter (Discard) | 9.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 277.000 MM |
| Outside Diameter | 10.906 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.500 MM |
| Mounting Hole Diameter | 0.571 IN |
| Nominal Drum Diameter | 228.600 MM |
| Nominal Drum Diameter | 9.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890032397 |
CENTRIC 122.44036 Cross References
| Brand | Part Number |
|---|---|
| 9752, 9634, BD126091 | |
| N/A | 0802686, 0832686, BD126091, E127-49-041, 80111, 35038, 35038G, 80111G, 116305, 592, 4243128100, 4243142010, 4243142011, 4243142050, 140691, 140782, 207620, DB4234, JBD382, E12749041, 100481, 87634, YH140782, 21108, 9752, 9634, 8822033, 36576035 |
| RAYBESTOS | 9752R, 9634, 9634R |
| Raybestos Brakes | 9752R |
| WAGNER | BD126091 |
CENTRIC 122.44036 Fits Vehicles
- Toyota RAV4 (1996-2005)
