Centric 122.36003 - Centric Premium Brake Drum
$6449
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 4.318 |
| Weight [cntrc] Lbs | 9.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 110.000 |
| Bolt Circle Diameter [cntrc] In | 4.331 |
| Hub Hole / Register [cntrc] Mm | 65.500 |
| Hub Hole / Register [cntrc] In | 2.579 |
| Height [cntrc] Mm | 67.800 |
| Height [cntrc] In | 2.669 |
| Friction Surface Width [cntrc] Mm | 49.130 |
| Friction Surface Width [cntrc] In | 1.934 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 231.000 MM |
| Maximum Brake Diameter (Discard) | 9.094 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 265.000 MM |
| Outside Diameter | 10.433 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.400 MM |
| Mounting Hole Diameter | 0.567 IN |
| Nominal Drum Diameter | 230.000 MM |
| Nominal Drum Diameter | 9.055 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890017257 |
Part Interchanges
CENTRIC 122.36003 Cross Reference
We have 4 alternatives for the 122.36003 by CENTRIC:
Fits Vehicles
- Saturn LW1 (2000)
- Saturn LS2 (2000)
- Saturn LS1 (2000)
- Saturn LS (2000)
- Saturn LW200 (2001-2003)
- Saturn L200 (2001-2003)
- Saturn L100 (2001-2002)
