CENTRIC 121.66043 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.66043 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 24.000 |
| Product Grade [cntrc] | Standard |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 10.910 |
| Discard Thickness | 26.500 MM |
| Discard Thickness | 1.043 IN |
| Nominal Thickness | 1.142 IN |
| Nominal Thickness | 29.000 MM |
| Overall Height | 85.700 MM |
| Overall Height | 3.374 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.630 IN |
| Center Hole Diameter | 117.600 MM |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890159230 |
CENTRIC 121.66043 Cross References
| Brand | Part Number |
|---|---|
| 1056830, 56830, 52125656 | |
| MAGMA PRODUCTS | PMR225238, PMR225213 |
| N/A | 52125656, BD125656, E126-71-048, 55057, 41243, BR55057, BR900562, 900562, 86830, 55120, 41243G, 55057G, 15712801, 145262, PRT5262, PRT5875, 101005, 56830, 56830R, 580380R, 1056830, 19326, AR8643E, 177860, 60048039, E12671048, 55057HC |
| PRONTO | BR55057 |
| RAYBESTOS | 56830, 56830FZN, 56830PER, 56830R, 56830R2 |
| WAGNER | BD125656, BD125656E |
CENTRIC 121.66043 Fits Vehicles
- GMC Sierra 1500 (2004)
- GMC Sierra 2500 (1999-2004)
- Hummer H2 (2003-2009)
- GMC Yukon XL 2500 (2000-2007)
- GMC Sierra 1500 HD (2001-2003, 2005-2006)
- Chevrolet Silverado 1500 (2004-2005)
- Chevrolet Avalanche 2500 (2002-2006)
- Chevrolet Suburban 2500 (2000-2007)
- GMC Sierra 1500 HD Classic (2007)
- Chevrolet Silverado 1500 HD Classic (2007)
- GMC Savana 2500 (2003-2021)
- GMC Savana 3500 (2004-2019, 2021-2022)
- Chevrolet Express 3500 (2004-2022)
- Chevrolet Express 2500 (2003-2009, 2011-2022)
- Chevrolet Silverado 2500 (1999-2004)
- Chevrolet Silverado 1500 HD (2001-2003, 2005-2006)
