(888) 312-8812 Login SignupCENTRIC 121.65015 C-Tek Standard Brake Rotor
Tap to view 4 more
$65.11
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.65015 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.65015 Specifications
Product Attributes
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 19.350 |
| Weight [cntrc] Kgs | 8.800 |
| Outer Bearing # [cntrc] | 410.91035 |
| Disc Mounting [cntrc] | Hub & Rotor |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91035 |
| Vane Style [cntrc] | Straight |
| Inner Seal # [cntrc] | 417.65007 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 20.600 MM |
| Discard Thickness | 0.811 IN |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.866 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 55.000 MM |
| Overall Height | 2.165 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 276.000 MM |
| Rotor Outside Diameter | 10.866 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890050421 |
CENTRIC 121.65015 Cross References
| Brand | Part Number |
|---|---|
| 6005, 6005RGS, 106005, 52-60693, 5260693, BD60693 | |
| MAGMA PRODUCTS | PMR205135 |
| N/A | BD60693, 52-60693, 5260693, E125-70-020, E126-70-020, 5448, BR5448, 64 92 640, R92 640, 107113, 5448G, E3TZ1102B, 141265, PRT1265, 102480, 102480E, 85791, 4885791, 594, AR8515, AR8515E, D6005, E12570020, E12670020, E8408, 69720260, 720260, X50329, 27033, BR1371, 6005, 6005R, 6005RGS, 106005, 106005R, ZAR8515E, 8942015, 78-42015, 7842015, 78942015, 65215, 60054111, 177663 |
| RAYBESTOS | 6005, 6005R |
| WAGNER | BD60693 |
CENTRIC 121.65015 Fits Vehicles
- Ford Bronco II (1984-1990)
- Ford Explorer (1991-1992)
- Ford Ranger (1983-1991)
