(888) 312-8812 Login SignupCENTRIC 121.63009 C-Tek Standard Brake Rotor
Tap to view 4 more
$10199
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 11
CENTRIC 121.63009 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.63009 Specifications
Product Attributes
| Inner Seal # [cntrc] | 417.63004 |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91017 |
| Weight [cntrc] Lbs | 6.200 |
| Product Grade [cntrc] | Standard |
| Vane Style [cntrc] | Straight |
| Outer Bearing # [cntrc] | 410.91002 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Kgs | 2.820 |
| Discard Thickness | 23.880 MM |
| Discard Thickness | 0.940 IN |
| Nominal Thickness | 25.400 MM |
| Nominal Thickness | 1.000 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 122.900 MM |
| Overall Height | 4.839 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 297.900 MM |
| Rotor Outside Diameter | 11.728 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 71.100 MM |
| Center Hole Diameter | 2.799 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890050063 |
CENTRIC 121.63009 Cross References
| Brand | Part Number |
|---|---|
| 7038, BD60474 | |
| N/A | BD60474, 5311, BR5311, 121.63009, 5311G, 4126545, 3880614, 3880615, PRT1132, 141132, 103110, 4885579, 85579, 543, AR8309, AR8309E, D17038, 5311DSR, 210167, YH141132, 5311DSL, X50163, BR1081, 7038R, 7038, 7832009, 8932009, 78-32009, 78932009, 60040003, 177585 |
| RAYBESTOS | 7038R |
| WAGNER | BD60474 |
CENTRIC 121.63009 Fits Vehicles
- Dodge St. Regis (1979-1981)
- Dodge Royal Monaco (1977)
- Dodge Monaco (1977-1978)
- Dodge Magnum (1978-1979)
- Dodge Coronet (1976)
- Dodge Charger (1976-1978)
- Chrysler Newport (1979-1981)
- Chrysler New Yorker (1979-1981)
- Chrysler Cordoba (1976-1979)
- Plymouth Gran Fury (1980-1981)
- Plymouth Fury (1976-1978)
