(888) 312-8812 Login SignupCENTRIC 121.46033 C-Tek Standard Brake Rotor
Tap to view 4 more
$4799
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Jun 16
CENTRIC 121.46033 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.46033 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 5.450 |
| Vane Style [cntrc] | Straight |
| Max Pb Drum Dia [cntrc] In | 6.654 |
| Product Grade [cntrc] | Standard |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 169.000 |
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 12.000 |
| Discard Thickness | 0.646 IN |
| Discard Thickness | 16.400 MM |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Overall Height | 65.600 MM |
| Overall Height | 2.583 IN |
| Outside Diameter | 265.600 MM |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Center Hole Diameter | 90.100 MM |
| Center Hole Diameter | 3.547 IN |
| Bearings Included | No |
| Nominal Drum Diameter | 6.614 IN |
| Nominal Drum Diameter | 168.000 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 10.457 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890048817 |
CENTRIC 121.46033 Cross References
| Brand | Part Number |
|---|---|
| 96160, 52-125142, 52125142, BD125142 | |
| MAGMA PRODUCTS | PMR143037 |
| N/A | 52-125142, 52125142, BD125142, 0802473, 0832473, 0832564, 31005, BR31005, MB587579, 31005G, 106835, 141773, PRT1773, 103051, 4886160, 86153, 86160, 308, JBR584, JBR584E, D17595, 1302964, 1.3029.6.4, 121.46033, MB311V, X50662, 25546, BR1746, 96160, 96160R, 8916029, 78-16029, 7816029, 78916029, 60072016 |
| PRONTO | BR31005 |
| RAYBESTOS | 96160R |
| WAGNER | BD125142 |
CENTRIC 121.46033 Fits Vehicles
- Dodge Stealth (1991-1996)
- Mitsubishi Diamante (1992-1996)
- Mitsubishi 3000GT (1991-1999)
