CENTRIC 121.45015 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.45015 Specifications
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 4.550 |
| Weight [cntrc] Lbs | 10.000 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 0.728 IN |
| Discard Thickness | 18.500 MM |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Overall Height | 34.500 MM |
| Overall Height | 1.358 IN |
| Outside Diameter | 250.000 MM |
| Outside Diameter | 9.843 IN |
| Mounting Bolt Hole Quantity | 4 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.953 IN |
| Center Hole Diameter | 75.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.701 IN |
| Mounting Bolt Hole Circle Diameter | 94.000 MM |
| Mounting Bolt Hole Diameter | 10.600 MM |
| Mounting Bolt Hole Diameter | 0.417 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890048428 |
CENTRIC 121.45015 Cross References
| Brand | Part Number |
|---|---|
| 96014, 52-61772, 5261772, BD61772 | |
| N/A | 0802152, 0832152, BD61772, 52-61772, 5261772, 3138, BR3138, R74 260, 64 74 260, 6474260, G09133251B, 3138G, 106600, GF3133251A, G09133251, G09133251A, G09133251C, GO9133251A, GO9133251B, GO9133251C, 809133251C, 112380, PRT1354, 141354, 4886014, 86014, 27, JBR314, JBR314E, D17271, 1.2610.2.4, 1261024, MZ121V, X50381, 25309, BR1488, 96014, 96014R, DF1998, 78914015, 78-14015, 7814015, 8914015, 63115, 60080010 |
| RAYBESTOS | 96014, 96014R |
CENTRIC 121.45015 Fits Vehicles
- Mazda 626 (1983-1987)
