CONVOLUTED PARTS
Trucks that run loaded one day and light the next depend on air springs to hold the frame steady, and the ContiTech Suspension Air Spring Kit is built for that routine. Pressure rises with the load and falls when the box is empty, so the same bag supports both conditions. Rubber flexes with every bump, which is why a bag eventually wears out. Fitting the ContiTech 64584 gives loaded and empty trips the same steady support.
| Assembly Weight | 25.5 |
| Design Height | 13 |
| Load At 100 Psi | 11100 |
| Load At 80 Psi | 8900 |
| Max Diameter | 15.9 |
| Max Height | 21.3 |
| Min Height | 4.4 |
| Nat Frequency | 62 |
| Brand | Part Number |
|---|---|
| Continental-ContiTech | AS7845 |
| Firestone | W01-358-7845 |
| Goodyear | 3B14-450 |
| Phoenix Air Springs | SP3B32RA-7845 |
| TRP | AS78450 |
| Triangle | 4521 |
| Triangle Air Springs | 4521 |
