Centric 120.74002 - Centric Premium Brake Rotor
$16149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | Hat Shaped |
| Weight [cntrc] Kgs | 13.410 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 29.500 |
| Product Grade [cntrc] | Premium |
| Nominal Thickness | 40.000 MM |
| Nominal Thickness | 1.575 IN |
| Overall Height | 54.100 MM |
| Overall Height | 2.130 IN |
| Outside Diameter | 310.000 MM |
| Outside Diameter | 12.205 IN |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.488 IN |
| Center Hole Diameter | 114.000 MM |
| Mounting Bolt Hole Circle Diameter | 140.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.512 IN |
| Mounting Bolt Hole Diameter | 10.200 MM |
| Mounting Bolt Hole Diameter | 0.402 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890370888 |
Part Interchanges
CENTRIC 120.74002 Cross Reference
We have 5 alternatives for the 120.74002 by CENTRIC:
Fits Vehicles
- Freightliner FL360 (2010-2012)
- Mitsubishi Fuso FE180 (2005-2011)
- Mitsubishi Fuso Canter FE180 (2012-2014)
- Mitsubishi Fuso Canter FE160 (2012-2014)
