CENTRIC 120.66048 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.66048 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Lbs | 12.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 1 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 5.680 |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9.000 MM |
| Nominal Thickness | 11.000 MM |
| Nominal Thickness | 0.433 IN |
| Hat Finish | Painted |
| Overall Height | 46.500 MM |
| Overall Height | 1.831 IN |
| Outside Diameter | 290.000 MM |
| Outside Diameter | 11.417 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 190.100 MM |
| Nominal Drum Diameter | 7.484 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.300 MM |
| Center Hole Diameter | 2.768 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.000 MM |
| Stud/Lug Hole Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890075158 |
CENTRIC 120.66048 Cross References
| Brand | Part Number |
|---|---|
| 580044, BD125774 | |
| N/A | BD125774, BD125774E, E125-71-053, BR5507802, 6493195, 55078, 55078G, 18060646, 101736, 145359, 48880044, 880044, AR8270, E12571053, 120.66048, 18026722, YH145359, 1407-25875, 27280, 2055078, 19991, 18A1423A, 177875, 90047068 |
| NEOTEK | 107276GF |
| Neotek Premium Drums and Rotors | 107276GF |
| PRONTO | BR5507802 |
| RAYBESTOS | 580044, 580044FZN, 580044R |
| Raybestos Brakes | 580044, 580044FZN, 580044R |
| WAGNER | BD125774E, BD125774 |
CENTRIC 120.66048 Fits Vehicles
- Pontiac Aztek (2001-2005)
- Oldsmobile Silhouette (2002-2004)
- Chevrolet Venture (2002-2004)
- Buick Rendezvous (2002-2007)
- Pontiac Montana (2002-2004)
