(888) 312-8812 Login SignupFRAM DL9972 Defense Filters, DL9972, Oil Filters
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FRAM DL9972 Part Description
CARTRIDGE OIL FILTER DEFENSE
FRAM DL9972 Specifications
Product Attributes
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Filter Media Material | Cellulose/Synthetic Blend |
| Filter Type | Cartridge |
| Grade | Advanced |
| Grade Type | Regular |
| Height | 2.64 IN |
| Inside Diameter Bottom | 1.100 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| Non Slip Grip | No |
| O-ring (1) Inside Diameter | 1.080 IN |
| O-ring (1) Outside Diameter | 1.220 IN |
| O-ring (1) Thickness | 0.140 IN |
| O-ring Inside Diameter | 3.150 IN |
| O-ring Outside Diameter | 3.290 IN |
| O-ring Thickness | 0.014 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.75 in |
| Outer Diameter Top | 2.75 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 1.100 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8421230000 |
| UPC | 00009100547286 |
| UNSPSC | 15121501 |
FRAM DL9972 Cross References
| Brand | Part Number |
|---|---|
| A.L. Solutions U.S. | ALO-8147 |
| ACDelco | PF2259 |
| Amsoil | EA15K02 |
| Auto Extra | 61857047 |
| Baldwin | P7398 |
| Beck/Arnley | 041-8190 |
| Bosch | 3972, 72236WS |
| Carquest | 84047, R84047, R84047MP |
| Carquest Premium Filters | 84047 |
| Casite Filters | CF607 |
| Castrol | CAS9972 |
| Certified | CCH9972 |
| Champ | P967, P967XL |
| Champion | 55047T, COC9972 |
| Champion Filters | 55047T, COC9972 |
| Defense Filters | DL9972 |
| Driveworks | DW-5608 |
| ECOGARD | X5608 |
| EXXON/MOBIL OIL | M1C251, M1C251A |
| FRAM | CH9972, M1C-251A, M1C-251, XG9972, TG9972, DL9972 |
| FRAM Core | COR9972ACC |
| FRAM Drive | FD9972 |
| FRAM Force | FF9972 |
| FRAM Pro | FP9972BP |
| FRAM Synthetic Endurance | FE9972 |
| FRAM Titanium | FS9972 |
| FRAM Tough Guard | TG9972 |
| FRAM Ultra Synthetic | XG9972 |
| FVP | G7047 |
| Factory Motor Parts | G7047 |
| Firestone | P967 |
| Forecast | OF50 |
| Group 7 | V5608 |
| Hastings | LF607, LF607F |
| Inter-Continental Gear & Brake | ALO-8147 |
| K&N | HP-7020, PS-7020 |
| LUBER-FINER | P967 |
| MIGHTY | M967 |
| MOBIL OIL | M1C251, M1C251A |
| Magneti Marelli | 1AMFL00021 |
| Mahle | OX414D1ECO |
| Mann-Filter | ML 1031 |
| MicroGard | MGL57047, MGL9972 |
| Mighty Distributing System | M967 |
| Mileguard | MO9972 |
| Mobil | MO5608 |
| Mobil 1 | M1C-251, M1C-251A |
| MotoMaster | MCH9972 |
| Motorcraft | FL-2060 |
| NAPA | 7047 |
| NAPA Platinum Filters | 47047 |
| NAPA ProSelect Filters | 27047 |
| NAPA Silver Filters | 37047 |
| PUROLATOR | TL25608 |
| Parts Master | 67047, 67047BP, 67047X |
| Parts Plus | P967, PL25608 |
| Pennzoil | HPZ-161, PZ-161, PZ161 |
| Pentius | PCB9972 |
| Performax | PO-161 |
| Pit Stop | PSL55 |
| Premium Guard | PG5608 |
| Prime Guard Filters - Archived | POF5608 |
| Promotive | PH5608 |
| Pronto | PO-5608 |
| PureZone | 8-57047 |
| Purolator | L25608 |
| Purolator BOSS | PBL25608 |
| Purolator PureONE | PL25608 |
| Purolator TECH | TL25608 |
| PurolatorONE | PL25608 |
| Quaker State | QS45516 |
| STP Filters | S9972, S9972ML, S9972XL |
| SUPERTECH | ST9972 |
| Service Champ | CF5608 |
| Silverline | 27047 |
| Super Tech Filters | ST9972 |
| Tough Guard | TG9972 |
| Toyota | 04152-31080, 04152-31090, 04152-31110, 04152-YZZA1 |
| Ultra | XG9972 |
| VIPER | 9972 |
| Valvoline | VO-84 |
| Warner | WP967 |
| Warner Filters | WP967 |
| Wix | 57047, 57047XP |
FRAM DL9972 Fits Vehicles
- Suzuki Aerio (2002)
- Lexus TX550h+ (2024-2026)
- Lexus RX450hL (2018-2022)
- Lexus RX350L (2018-2022)
- Lexus NX300 (2018-2021)
- Lexus GS300 (2018-2019)
- Lexus RC300 (2018-2025)
- Lexus IS300 (2018-2025)
- Lexus LS500 (2018-2019)
- Lexus LS500h (2018-2025)
- Lexus LC500h (2018-2025)
- Lexus IS350 (2017-2026)
- Lexus RC350 (2017-2025)
- Toyota Venza (2009-2016)
- Lexus RC200t (2016-2017)
- Lexus GS350 (2016-2020)
- Lexus GS200t (2016-2017)
- Toyota Tacoma (2016-2023)
- Lexus IS200t (2016-2017)
- Lexus NX200t (2015-2017)
- Lexus NX300h (2015-2021)
- Lexus ES300h (2013-2018)
- Scion tC (2011-2016)
- Lotus Evora (2010-2014, 2016-2017)
- Lexus RX450h (2010-2022)
- Lexus IS250 (2008, 2013)
- Toyota Highlander (2008-2022)
- Toyota Sienna (2007-2020)
- Lexus RX350 (2007-2022)
- Lexus ES350 (2007-2025)
- Toyota Camry (2007-2024)
- Toyota RAV4 (2006-2018)
- Toyota Avalon (2005-2022)
FRAM DL9972 Customer Reviews
No reviews yet
Be the first to review this product!
FRAM DL9972 Manufacturer Information
FRAM® is all-set to "Filter out the Nonsense." With an origin that dates back to 1932, this brand has been globally recognized as the filter authority for its world-class filtering solutions that offer maximum engine protection, unparalleled filtering performance, and superior dirt-holding capacity. FRAM provides the industry with first-rate air filters, oil filters, heavy-duty commercial filters that help keep engines running efficiently, the way a well-filtered machine should. Among FRAM's popular products are the FRAM Extra Guard air filter, Fresh Breeze cabin air filter, Titanium oil filter, heavy-duty hydraulic, coolant, or fuel filters, and many others. Whether you are a fleet manager, a seasoned mechanic, or an experienced do-it-yourselfer, FRAM will provide you with filters that deliver efficiency, quality, reliability, performance, and durability at competitive prices.
