CENTRIC 120.65113 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65113 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 207.200 |
| Weight [cntrc] Kgs | 13.910 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 8.157 |
| Weight [cntrc] Lbs | 30.600 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.276 IN |
| Discard Thickness | 32.400 MM |
| Nominal Thickness | 1.339 IN |
| Nominal Thickness | 34.000 MM |
| Hat Finish | Painted |
| Overall Height | 4.976 IN |
| Overall Height | 126.400 MM |
| Outside Diameter | 340.000 MM |
| Outside Diameter | 13.386 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.996 IN |
| Center Hole Diameter | 126.900 MM |
| Mounting Bolt Hole Circle Diameter | 6.693 IN |
| Mounting Bolt Hole Circle Diameter | 170.000 MM |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.070 MM |
| Stud/Lug Hole Diameter | 0.633 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890465201 |
CENTRIC 120.65113 Cross References
| Brand | Part Number |
|---|---|
| 680394, BD126274 | |
| N/A | 120.65113, BD126274E, BD126274, E125-70-118, BR5414102, 54141GT, 144211, 5C342C026A, 1407-80391, YH145730, 54141, BRRF50, 54141G, 5U2Z1V125MC, 6C3Z2C026AA, 5C3Z2C026AA, 5C3Z2C026AB, 5U2Z1V125M, 9C3Z2C026A, 880394, 2054141, 90054199, E12570118, 54141HC |
| NEOTEK | 1071089GF |
| Neotek Premium Drums and Rotors | 1071089GF |
| PRONTO | BR5414102 |
| RAYBESTOS | 680394, 680394FZN, 680394PER, 680394R, 680394R2 |
| Raybestos Brakes | 680394, 680394FZN, 680394PER, 680394R |
| WAGNER | BD126274, BD126274E |
CENTRIC 120.65113 Fits Vehicles
- Ford F-350 Super Duty (2005-2012)
- Ford F-250 Super Duty (2005-2012)
