(888) 312-8812 Login SignupCENTRIC 120.65107 Centric Premium Brake Rotor
Tap to view 4 more
$82.93
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.65107 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65107 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 8.180 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 18.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 24.000 MM |
| Discard Thickness | 0.945 IN |
| Nominal Thickness | 26.000 MM |
| Nominal Thickness | 1.024 IN |
| Hat Finish | Painted |
| Overall Height | 46.700 MM |
| Overall Height | 1.839 IN |
| Outside Diameter | 302.800 MM |
| Outside Diameter | 11.921 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.835 IN |
| Center Hole Diameter | 72.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.150 MM |
| Stud/Lug Hole Diameter | 0.557 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890221821 |
CENTRIC 120.65107 Cross References
| Brand | Part Number |
|---|---|
| 680272, BD126197 | |
| ADVICS | K6F141U |
| N/A | BD126197, BD126197E, E125-70-112, BR5412302, 54123, BRRF84, 54123G, 5L8Z1125AA, 5U2Z1V125N, EF913325X, AL8Z1125A, ZZDL3325X, 880272, AR85103, E12570112, 54123HC, 120.65107, 5L841032A, 5L841032AA, 0106, 1141, YH145583, 1407-23960, 27401, 2054123, 19360, 18A1707A, 90054193 |
| NEOTEK | 1071039GF |
| Neotek Premium Drums and Rotors | 1071039GF |
| PRONTO | BR5412302 |
| RAYBESTOS | 680272, 680272FZN, 680272R, 680272R2 |
| Raybestos Brakes | 680272, 680272FZN, 680272R |
| WAGNER | BD126197, BD126197E |
CENTRIC 120.65107 Fits Vehicles
- Mazda Tribute (2005-2006, 2008-2011)
- Mercury Mariner (2005-2011)
- Ford Escape (2005-2012)
