CENTRIC 120.65076 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65076 Specifications
Product Attributes
| Disc Mounting [cntrc] | Hub & Rotor |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 20.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Outer Bearing # [cntrc] | 410.91002 |
| Weight [cntrc] Kgs | 9.090 |
| Vane Style [cntrc] | Straight |
| Inner Bearing # [cntrc] | 410.91005 |
| Inner Seal # [cntrc] | 417.61003 |
| Discard Thickness | 24.500 MM |
| Discard Thickness | 0.965 IN |
| Nominal Thickness | 26.100 MM |
| Nominal Thickness | 1.028 IN |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 108.000 MM |
| Overall Height | 4.252 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 261.000 MM |
| Rotor Outside Diameter | 10.276 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.400 MM |
| Center Hole Diameter | 2.772 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890036074 |
CENTRIC 120.65076 Cross References
| Brand | Part Number |
|---|---|
| 66672, BD125777 | |
| N/A | 0832699, 0832766, BD125777, BD125777E, E125-70-081, 6492215, 64 92 215, 54058, 107178, 54058G, ZZR033251, ZZR033251A, XL5Z1102BA, ZZP033251, 1F0133251, F87A1102BB, F87Z1102BB, 145189, 4886672, 86672, 86768, AR8576, E12570081, 120.65076, YH145189, 1407-25652, 27079, 66672, ZAR8576, 19849, 78-42076, 7842076, 8942076, 60054165 |
| RAYBESTOS | 66672FZN, 66672R |
| Raybestos Brakes | 66672FZN, 66672R |
| WAGNER | BD125469, BD125777E, BD125777 |
CENTRIC 120.65076 Fits Vehicles
- Ford Ranger (1998-2001)
- Mazda B4000 (1998-2000)
- Mazda B3000 (1998-2000)
- Mazda B2500 (1998-2000)
