CENTRIC 120.65063 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65063 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Bearing # [cntrc] | 410.91018 |
| Outer Bearing # [cntrc] | 410.91012 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 12.730 |
| Weight [cntrc] Lbs | 28.000 |
| Inner Seal # [cntrc] | 417.65000 |
| Discard Thickness | 27.700 MM |
| Discard Thickness | 1.091 IN |
| Nominal Thickness | 30.100 MM |
| Nominal Thickness | 1.185 IN |
| Hat Finish | Coated |
| Stud Thread Diameter | 12.000 MM |
| Overall Height | 102.900 MM |
| Overall Height | 4.051 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 308.000 MM |
| Rotor Outside Diameter | 12.126 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.750 MM |
| Bearings Included | No |
| Center Hole Diameter | 86.700 MM |
| Center Hole Diameter | 3.413 IN |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890043607 |
CENTRIC 120.65063 Cross References
| Brand | Part Number |
|---|---|
| 66653, BD125510, BD125689 | |
| N/A | BD125510, BD125689, E125-70-068, 6492290, 54050, 54050G, 107173, F75A1102BC, F75A1102BD, F75Z1102BD, F85A1102BA, F85Z1102BA, XL3Z1102AA, XL1Z1102AD, XL1Z1102AF, 102557E, 145141, 4886653, 86648, 86653, AR8563, E12570068, E12330, 12886501, 210762C, YH145141, 27077, 19926, 8942063, 60054153 |
| NEOTEK | 107173GF |
| Neotek Premium Drums and Rotors | 107173GF |
| RAYBESTOS | 66653, 66653R |
| Raybestos Brakes | 66653, 66653R |
| WAGNER | BD125689, BD125689E |
CENTRIC 120.65063 Fits Vehicles
- Lincoln Navigator (1998-2000)
- Ford F-150 (1999)
- Ford Expedition (1997-2000)
