Centric 120.65063 - Centric Premium Brake Rotor
$10499
MSRP: $143.20
Save: $38.21
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Bearing # [cntrc] | 410.91018 |
| Outer Bearing # [cntrc] | 410.91012 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 12.730 |
| Weight [cntrc] Lbs | 28.000 |
| Inner Seal # [cntrc] | 417.65000 |
| Discard Thickness | 27.700 MM |
| Discard Thickness | 1.091 IN |
| Nominal Thickness | 30.100 MM |
| Nominal Thickness | 1.185 IN |
| Hat Finish | Coated |
| Stud Thread Diameter | 12.000 MM |
| Overall Height | 102.900 MM |
| Overall Height | 4.051 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 308.000 MM |
| Rotor Outside Diameter | 12.126 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.750 MM |
| Bearings Included | No |
| Center Hole Diameter | 86.700 MM |
| Center Hole Diameter | 3.413 IN |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890043607 |
Part Interchanges
- Raybestos Brakes 66653
- Raybestos Brakes 66653R
- Neotek Premium Drums and Rotors 107173GF
- BD125510
- BD125689
- E125-70-068
- 6492290
- 54050
- 54050G
- 107173
- F75A1102BC
- F75A1102BD
- F75Z1102BD
- F85A1102BA
- F85Z1102BA
- XL3Z1102AA
- XL1Z1102AD
- XL1Z1102AF
- 102557E
- 145141
- 4886653
- 86648
- 86653
- AR8563
- E12570068
- E12330
- 12886501
- 210762C
- YH145141
- 27077
- 19926
- 8942063
- 60054153
CENTRIC 120.65063 Cross Reference
We have 6 alternatives for the 120.65063 by CENTRIC:
Fits Vehicles
- Lincoln Navigator (1998-2000)
- Ford F-150 (1999)
- Ford Expedition (1997-2000)
