(888) 312-8812 Login SignupCENTRIC 120.65062 Centric Premium Brake Rotor
Tap to view 4 more
$87.22
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.65062 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65062 Specifications
Product Attributes
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Pillar |
| Weight [cntrc] Lbs | 18.000 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 8.180 |
| Discard Thickness | 1.091 IN |
| Discard Thickness | 27.700 MM |
| Nominal Thickness | 1.169 IN |
| Nominal Thickness | 29.700 MM |
| Hat Finish | Painted |
| Overall Height | 47.200 MM |
| Overall Height | 1.858 IN |
| Outside Diameter | 307.800 MM |
| Outside Diameter | 12.118 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 92.500 MM |
| Center Hole Diameter | 3.642 IN |
| Mounting Bolt Hole Circle Diameter | 5.906 IN |
| Mounting Bolt Hole Circle Diameter | 150.000 MM |
| Stud/Lug Hole Quantity | 7 |
| Stud/Lug Hole Diameter | 0.591 IN |
| Stud/Lug Hole Diameter | 15.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890035978 |
CENTRIC 120.65062 Cross References
| Brand | Part Number |
|---|---|
| 66648, BD125529 | |
| N/A | BD125529, BD125529E, E125-70-067, 6492105, 64 92 105, 54048, 54048G, 107160, F75A1125AC, F75W2B663AA, F75W2C300AA, F75Z1125AC, XL3Z1102BA, XL3Z1102CA, XL3Z1125BA, YL3Z1V125EA, 145145, 4886648, 86671, 86648, AR8562, E12570067, 120.65062, 210792, YH145145, 1407-25163, X51185, 27078, 19867, 60054152 |
| RAYBESTOS | 66648, 66648FZN, 66648R |
| Raybestos Brakes | 66648, 66648FZN, 66648R |
| WAGNER | BD125529, BD125529E |
CENTRIC 120.65062 Fits Vehicles
- Ford F-150 Heritage (2004)
- Ford F-250 (1997-1999)
- Ford F-150 (2000-2003)
- Ford F-250 HD (1997)
