CENTRIC 120.65057 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65057 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 19.250 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.750 |
| Discard Thickness | 0.965 IN |
| Discard Thickness | 24.500 MM |
| Nominal Thickness | 26.000 MM |
| Nominal Thickness | 1.024 IN |
| Hat Finish | Painted |
| Overall Height | 52.000 MM |
| Overall Height | 2.047 IN |
| Outside Diameter | 308.000 MM |
| Outside Diameter | 12.126 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 90.000 MM |
| Center Hole Diameter | 3.543 IN |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.598 IN |
| Stud/Lug Hole Diameter | 15.200 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890043560 |
CENTRIC 120.65057 Cross References
| Brand | Part Number |
|---|---|
| 66630, BD125512 | |
| N/A | BD125512, BD125512E, E125-70-062, 153145146, BR5404202, 54042, 107171, 54042G, F65Z1125AC, YL3Z1125AA, YL3Z1V125DA, XL3Z1125CB, 145146, 86630, 86822, 4886630, AR8557, E12570062, 54042HC, 120.65057, 54042GT, 54042DSR, SD54042L, SD54042R, YH145146, 1407-25665, 54042DSL, 27015, X51207, 66630P, 2054042, 19773, 8942057, 90054147 |
| NEOTEK | 107171GF |
| Neotek Premium Drums and Rotors | 107171GF |
| PRONTO | BR5404202 |
| RAYBESTOS | 66630, 66630FZN, 66630PER, 66630R, 66630R2 |
| Raybestos Brakes | 66630, 66630FZN, 66630PER, 66630R |
| WAGNER | BD125512E, BD125512 |
CENTRIC 120.65057 Fits Vehicles
- Ford F-150 Heritage (2004)
- Ford F-150 (1997-2003)
