RAYBESTOS 66630PER Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance S-Groove Brake Rotor
Application Summary
2004-1997 Ford F-150 Front, 2004 Ford F-150 Heritage Front
RAYBESTOS 66630PER Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.55 IN |
| Center Hole Diameter | 90.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.965 IN |
| Discard Thickness | 24.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Mounting Bolt Hole Circle Diameter | 135 MM |
| Mounting Bolt Hole Diameter | 0.588 IN |
| Mounting Bolt Hole Diameter | 14.95 MM |
| Nominal Thickness | 1.025 IN |
| Nominal Thickness | 26.05 MM |
| Outside Diameter | 12.12 IN |
| Outside Diameter | 307.85 MM |
| Overall Height | 2.045 IN |
| Overall Height | 51.95 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Solid Or Vented Type Rotor | Vented |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Quantity | 5 |
| Material | Cast Iron |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352747841 |
RAYBESTOS 66630PER Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 145146, YH145146 |
| AMERICAN REMANUFACTURED | 789-42057, 89-42057 |
| AUTOPART INTERNATIONAL | 25665 |
| AUTOSPECIALTY | AR8557, AR8557E |
| Advance Auto Parts | YH145146C, YH145146P |
| AutoZone | 54042, 54042B, 54042DG, 54042DL, DL54042 |
| Autoxtra | AX54042 |
| BENDIX | 145146, PRT5146 |
| BOSCH | RBR54042 |
| BRAKE HEADQUARTERS | BR54452 |
| BRAKEBEST | 81-125512, BD125512 |
| BREMBO | 09.7787.10, 27015 |
| BrakeBest | 20010308, 66630, 66630FZN, 66630PER, 66630R, 66630RGS |
| Brembo | 09.7787.11 |
| CALIFORNIA DRUM & ROTOR | 125512 |
| CENTRIC | 120.65057, 121.65057, 125.65057 |
| CONTINENTAL-CONTITECH | CW26715 |
| Casting Numbers | 210733-C, 325216, 5192, 540421 |
| Centric Parts | 120.65057, 121.65057, 125.65057, 120.65057CRY, 125.65057CRY, 126.65057CSL, 126.65057CSR, 126.65057SL, 126.65057SR, 127.65057CL, 127.65057CR, 127.65057L, 127.65057R, 128.65057CL, 128.65057CR, 128.65057L, 128.65057R, 227.65057L, 227.65057R, 320.65057, 320.65057F, 321.65057 |
| DELPHI | RB584 |
| DURA CORP | BR54042 |
| Dura Corp | BR5404202 |
| DuraGo | BR54042, BR54042-02 |
| FORD | F65Z1125AC, XL3Z1125CB |
| FORMULA BLUE HYDRAULIC BRAKE PARTS | E12570062 |
| Ford | YL3Z1125AA, YL3Z1V125DA, YL3Z1V125DB |
| GREN | 649002 |
| GUARDIAN | 52-125512 |
| MIDAS | BR2051 |
| MOTORCRAFT | BRR62 |
| Mighty Distributing System | 54042 |
| Monroe Brakes | BD125512 |
| Motorcraft | NBRR6 |
| Newtek Automotive USA | 54042 |
| PARTS MASTER | P125512 |
| Parts Master | 125512 |
| PowerStop | AR8557EVC |
| QUALIS | 54042 |
| QUALITY BRAND | 54042, Q4111 |
| STANDARD ROTORS AND DRUMS | 54042 |
| THE UNIVERSAL GROUP | 102567 |
| TopNotch | TN66630GEO |
| UAP | 54042 |
| Universal | 102567 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51207 |
| WABCO - Archived | PS125512 |
| WAGNER BRAKE | BD125512 |
| WINHERE | YH2409 |
| WORLDPAC | 1407-25665 |
| Wagner Brake | BD125512E |
| Winhere | 662409 |
RAYBESTOS 66630PER Fits Vehicles
- Ford Lobo (2002-2003)
- Ford F-150 Heritage (2004)
- Ford F-150 (1997-2004)
