(888) 312-8812 Login SignupCENTRIC 120.62062 Centric Premium Brake Rotor
Tap to view 4 more
$67.69
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.62062 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.62062 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 190.400 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 14.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.450 |
| Vane Style [cntrc] | Pillar |
| Max Pb Drum Dia [cntrc] In | 7.496 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.945 IN |
| Discard Thickness | 24.000 MM |
| Nominal Thickness | 1.020 IN |
| Nominal Thickness | 25.900 MM |
| Hat Finish | Painted |
| Overall Height | 48.400 MM |
| Overall Height | 1.906 IN |
| Outside Diameter | 305.000 MM |
| Outside Diameter | 12.008 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 190.100 MM |
| Nominal Drum Diameter | 7.484 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.700 MM |
| Center Hole Diameter | 2.783 IN |
| Mounting Bolt Hole Circle Diameter | 4.748 IN |
| Mounting Bolt Hole Circle Diameter | 120.600 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.500 MM |
| Stud/Lug Hole Diameter | 0.531 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890035657 |
CENTRIC 120.62062 Cross References
| Brand | Part Number |
|---|---|
| 56703, 580252, BD125558, BD126283 | |
| N/A | BD125558, BD126283, 6493045, 55046GT, 55045DSR, 55046, YH145169, 55100, 27196, 27292, 55046G, 10406650, 10445858, 88955498, 10262998, 101935, 56703P, 145169, 86703, 8936062, AR8262, 1770962, 177838, 177855, 18A949 |
| RAYBESTOS | 56703, 56703R, 580252, 580252R |
| Raybestos Brakes | 56703, 56703R, 580252 |
| WAGNER | BD125558 |
CENTRIC 120.62062 Fits Vehicles
- Cadillac XLR (2004-2009)
- Chevrolet Corvette (1997-2013)
