CENTRIC 120.50023 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.50023 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 4.860 |
| Weight [cntrc] Lbs | 10.700 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 8.400 MM |
| Discard Thickness | 0.331 IN |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10.000 MM |
| Hat Finish | Painted |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 275.000 MM |
| Outside Diameter | 10.827 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 2.992 IN |
| Center Hole Diameter | 76.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.484 IN |
| Stud/Lug Hole Diameter | 12.300 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890395911 |
CENTRIC 120.50023 Cross References
| Brand | Part Number |
|---|---|
| 980599, 980599R, BD126588 | |
| ADVICS | R6R322U |
| ATE BRAKE PRODUCTS | 410341 |
| N/A | 120.50023, BD126588, BD126588E, BR90058602, YH200446, 44639, 31493G, 584111D000, 44701, 980599, 31493, DDF1752, 90021010 |
| NEOTEK | 1069009GF |
| Neotek Premium Drums and Rotors | 1069009GF |
| RAYBESTOS | 980599FZN, 980599R |
| Raybestos Brakes | 980599FZN, 980599R |
| WAGNER | BD126588, BD126588E |
CENTRIC 120.50023 Fits Vehicles
- Kia Rondo (2007-2012)
