(888) 312-8812 Login SignupNGK SPARK PLUGS 93560 NGK Laser Iridium High Ignitability Spark Plug
Tap to view 4 more
$2549
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
NGK SPARK PLUGS 93560 Part Description
Manufacturer
Product Description
NGK Laser Iridium High Ignitability Spark Plug
Features & Benefits
- NGK Laser Iridium High Ignitability spark plugs are designed with the most advanced OE tip configurations to maximize service life and combustion efficiency resulting in a quicker throttle response, smoother idle and better cold starts.
- ACTUAL OE or EQUIVALENT HIGH IGNITABILITY DESIGN: SPE tip and iridium alloy center electrode produce the most advanced OE spark plug technology
- IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
- SPE DESIGN: Square platinum electrode shape of the ground electrode provides the best ignitability and service life for high heat engines
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Best for vehicles with OE SPE iridium alloy plugs
Laser Iridium Plug
NGK SPARK PLUGS 93560 Specifications
Product Attributes
| Stock Number | 93560 |
| Part Number | SILKGR9A7ES |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Square Platinum Electrode (SPE) - High Ignitability |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Copper |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 0.5511811024 IN |
| Insulator Height | 51.00 MM |
| Manufacturer Heat Range | 9 |
| Seat Type | Flat |
| Reach | 1.043 IN |
| Thread Diameter | 12.00 MM |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Hex Size | 14mm Bi-Hex |
| Insulator Height | 2.01 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Platinum |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.14 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Short Style Spark Plug | No |
| Service Number | SILKGR9A7ES |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295935606 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS 93560 Part Interchanges
| Brand | Part Number |
|---|---|
| NGK | 93560 |
| Volkswagen | 06M905606F |
NGK SPARK PLUGS 93560 Fits Vehicles
- Audi SQ5 Sportback (2021-2024)
- Porsche 911 (2021-2024)
- Audi Q7 (2020-2024)
- Audi S7 Sportback (2020-2024)
- Audi A6 allroad (2020-2024)
- Audi S7 (2020)
- Audi S6 (2020-2024)
- Audi A7 Sportback (2019-2024)
- Audi A6 Quattro (2019-2024)
- Porsche Macan (2019-2024)
- Audi A8 Quattro (2019-2024)
- Audi Q8 (2019-2025)
- Porsche Cayenne (2019-2024)
- Audi RS5 Sportback (2019, 2021-2024)
- Audi S5 Sportback (2018-2024)
- Audi RS5 (2018-2019, 2021-2024)
- Audi S5 (2018-2024)
- Audi SQ5 (2018-2024)
- Audi S4 (2018-2024)
- Porsche Panamera (2017-2023)
NGK SPARK PLUGS 93560 Manufacturer Information
Headquartered in Wixom, Michigan, NGK® is a global leader in the design and manufacture of spark plugs for virtually every automotive and commercial vehicle application. It has grown immensely since its inception in 1936 with the expansion of its ignition product line and the introduction of its technical sensor and vehicle electronics line. NGK partners with OEMs and uses only the latest cutting tools to ensure each NGK product meets OE specifications for exact fit, form, and function. With world-class quality and engineering, NGK’s expertise goes beyond manufacturing the most reliable spark plugs for the automotive industry but also providing the best customer service possible.
