NATIONAL SEALS part description

Product Description

Wheel Seal

Application Summary

1992-2001 AM General Hummer (Rear Inner, Front Inner); 2002-2006 Hummer H1 (Rear Inner, Front Inner)

Features & Benefits

  • Design type: spring loaded; multi-lip
  • Temperature range: -100°F to 450°F / -73°C to 232°
  • Temperature range: -100degF to 450degF / -73degC to 232deg
  • Excellent dry running capabilities
  • Low coefficient of friction
  • Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter 3.504 IN
Inside Diameter 89.000 MM
Outside Diameter 4.260 IN
Outside Diameter 108.200 MM
Width 0.500 IN
Width 12.700 MM
Material PTFE
Housing Bore 4.252 IN
Housing Bore 108.000 MM
Part Description Oil Seal
Series 710500
Shaft Diameter 3.504 IN
Shaft Diameter 89.000 MM
Type 32
Unit of Dimension Metric
Grade Type Premium

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 4016931020
Harmonized Tariff Code (HTS) 4016931020
Canadian Harmonizing Tariff Code 4016930000
UPC 00614046950443

Part Interchanges

Fits Vehicles

  • AM General Hummer (1992-2001)
  • Hummer H1 (2002-2004, 2006)
