CENTRIC 320.46064H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.46064H Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 10.000 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 22.000 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| Stud/Lug Hole Diameter | 0.496 IN |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69.000 MM |
| Bearings Included | No |
| Nominal Drum Diameter | 5.787 IN |
| Nominal Drum Diameter | 147.000 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320.000 MM |
| Overall Height | 1.713 IN |
| Overall Height | 43.500 MM |
| Hat Finish | Coated |
| Disc Finish | Fully Coated |
| Nominal Thickness | 1.260 IN |
| Nominal Thickness | 32.000 MM |
| Discard Thickness | 1.173 IN |
| Discard Thickness | 29.800 MM |
CENTRIC 320.46064H Cross References
CENTRIC 320.46064H Fits Vehicles
- Mitsubishi Lancer (2003-2006)
