Name: Gates 85076 MXT MegaSys Wire Braid Hose - SAE 100R16 - Xtra Tough Plus
SKU: 85076
Price: 579.99 USD
Availability: InStock

GATES 85076 Part Description

MXT MegaSys Wire Braid Hose - SAE 100R16 - Xtra Tough Plus

For use with MegaCrimp Couplings [G25 Series]
Tested to industry-leading 600,000 impulse cycles
More flexible with up to 40 percent lower force-to-bend for faster and more ergonomic installation
Provides bend radius up to 1/3 of the SAE specification and greater flexibility for easier routing
Meets Flame Resistance Acceptance Designation MSHA 2G
Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
The XtraTuff Plus cover on MXT hose offers improved abrasion & ozone resistance, delivering increased durability to power your most demanding fluid power applications
Does not impact the flexibility advantages of MXT cover

GATES 85076 Specifications

Industrial Description	8MXT-XTPX50FT
Type	Hydraulic Hose
Hose Pressure Description	High Pressure
Maximum Working Pressure	4000 PS
Burst Pressure	16000 PS
Temperature Rating	-40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Length	50 F
Dash Size	8
Inside Diameter	.5 IN
Outside Diameter	.795 IN
Bend Radius	2.8
Tube Description	Black, Oil Resistant, Synthetic Rubber
Hose Material	Nitrile
Reinforcement Material	One Braid, High-Tensile Steel Wire
Cover Material	Synthetic Rubber - Nitrile - Type C2 - Color Coded Layline
Cover Type	Flame, Oil & Ozone Resistant
Cover Color	Blue & Black
Coupling Recommendation	MegaCrimp
SAE Standard	SAE 100R16
EN Standard	EN 853 2SN, EN 857 2SC
ISO Standard	N/A
Product Type	MXT MegaSys Wire Braid Hose - SAE 100R16 - Xtra Tough Plus

Harmonized Tariff Code (Schedule B)	4009210000
Country of Origin (Primary)	MX
UPC	00770075829843
VMRS Code	059032029
UNSPSC	40142020

Brand	Part Number
NAPA	85076
