32006 by GATES - SUPER HEX HEAD
Tap to view 1 more
32006 by GATES - SUPER HEX HEAD

Gates 32006 - SUPER HEX HEAD

Part Number
32006
Manufacturer
GATES
Description

SUPER HEX HEAD

details

$1.67

In stock

limited availability at this price!

New! No hassle Return Policy details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day
Get it by Thursday, Oct 30
Pay over 3-12 months with Affirm Logo. Learn more

GATES part description

Product Description

Stainless Steel Hose Clamp

Features & Benefits

  • Durable 200 series stainless steel band and screw housing
  • One-piece screw housing is interlocked onto band for extra strength
  • Cadmium-plated solid head forged from one piece of steel
  • Hex-shaped screw has a deep slot that tightens with a screwdriver, nut driver or socket wrench
  • NOTE: Tighten Minex clamps to minimum 14-16 in. lb. (maximum of 20 in. lb.)
  • NOTE: Super Hex clamps to minimum 25-35 in. lb. (maximum of 50 in. lb.)

Product Attributes

Adjustment Type Stainless Steel (Standard)
Hose Clamp Size 6
Hose Minimum Inside Diameter .25 IN
Hose Maximum Inside Diameter .375 IN
Minimum Clamping Length .375 IN
Maximum Clamping Length .875 IN
Band Width .5 IN
Screw Type Deep Slot Hex-Head
Recommended Torque 25-35 PPI
Maximum Torque 50 IA
Material Stainless Steel
Housing Material Stainless Steel
Band Width 13 MM

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 7326908688
UPC 00072053021592
VMRS Code 053008020
UNSPSC 31162900

Part Interchanges

GATES 32006 Cross Reference

We have 2 alternatives for the 32006 by GATES:

California Proposition 65 Warning California residents see Prop 65 Warning(s)
