WABCO 9750091010 - Air Brake Limiting Valve
$40949
3 day lead time
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
Pressure Limiting Unit
Product Attributes
| Nominal Diameter | 1.0 mm |
| Max. operating pressure | 145.0 psi |
| Voltage | 12 V |
| Weight | 1.3735 |
| Nominal flow rate | 0.025 (L/min) |
| Mounting | 2x Ø 8 mm |
| Max. operating pressure | 10.0 bar |
| Port thread 11 | 3/8" - 18 NPTF JED - 686 |
| Port thread 12 | 3/8" - 18 NPTF JED - 686 |
| Port thread 2 | 3/8" - 18 NPTF JED - 686 |
| Temperature Range | -40°C to +80°C |
| Electrical connection | Bayonet DIN 72585 A1-2.1-Sn/K2 |
| Port thread 3 | Flap Exhaust |
| Delivered Pressure | 5.5 at p1 = 9 bar |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
