DORMAN part description

Product Description

Pre-Pressed Rear Axle

Application Summary

Toyota Tacoma 2015-05

Features & Benefits

  • Easier installation - this loaded axle assembly includes a pre-assembled new axle shaft, wheel bearing, hub and backing plate
  • Instalación más fácil: este ensamble de eje cargado incluye un nuevo eje propulsor, rodamiento de rueda, maza y placa de soporte preensamblados
  • Time saver - eliminates frustrating, unpredictable work required to replace bearings without damaging other components
  • Ahorra tiempo: elimina el trabajo frustrante e impredecible necesario para reemplazar los cojinetes sin dañar otros componentes
  • Simpler solution - eliminates the need to use potentially dangerous shop press to perform complete bearing repair
  • Solución más simple: elimina la necesidad de usar la prensa de taller, potencialmente peligrosa, para realizar una reparación completa de los rodamientos
  • Quality tested - this part has undergone try-on, corrosion and material testing to ensure a quality fit and long service life
  • Calidad garantizada: esta parte se ha sometido a pruebas de uso en el vehículo, de corrosión y de materiales para garantizar un ajuste de calidad y una larga vida útil

Axle, Shaft, Assembly, Assemblies, Shafts, Axles

Product Attributes

Wheel Bolt Pattern Size 139.7 MM
Rust Resistant Coating Yes
Wheel Studs Included Yes
Inboard Spline Quantity 30
Outboard Spline Quantity 30
ABS Tone Ring Included Yes
Shaft Diameter 33 MM
Differential Case Design Type Semifloating
Wheel Stud Thread Diameter 12 MM
Brake Hardware Included No
Wheel Stud Thread Pitch 1.5 MM
Brake Dust Shield Included Yes
Brake Backing Plate Included Yes
Axle Shaft Seal Included Yes
Hub Bearing Included Yes
Adjustable No
Compressed Length 847.75 mm
Length 847.75 mm
Material Carbon Steel
Package Contents 1 Axle Shaft and Bearing Assembly; 1 Axle Seal; 1 Axle O-ring

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708995800
UPC 00037495919531
VMRS Code 022002001
UNSPSC 25173807

Part Interchanges

Fits Vehicles

  • Toyota Tacoma (2005-2015)
