(888) 312-8812 Login SignupWAGNER BD180446E Wagner Brake BD180446E Disc Brake Rotor
$8249
Limited availability at this price!
In Stock
Get as soon as Wednesday, Sep 30
WAGNER BD180446E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
2011-2016 Mini Cooper Countryman S S ALL4 (Front) (Aspiration: Turbocharged / Qualifier: with 307 (mm) Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion); 2013-2016 Mini Cooper Paceman S S ALL4 John Cooper Works ALL4 (Front) (Qualifier: with 307 (mm) Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD180446E Specifications
Product Attributes
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 307.0 MM |
| Surface Type | Smooth |
| Part Description | Disc Brake Rotor |
| Stud/Lug Hole Quantity | 5 |
| Outside Diameter | 12.087 IN |
| Overall Height | 1.772 IN |
| Overall Height | 45.0 MM |
| Nominal Thickness | 24.0 MM |
| Nominal Thickness | 0.945 IN |
| Solid Or Vented Type Rotor | Vented |
| Material | Cast Iron |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.114 IN |
| Center Hole Diameter | 79.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 22.4 MM |
| Discard Thickness | 0.882 IN |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.0 MM |
| Mounting Bolt Hole Diameter | 16.8 MM |
| Mounting Bolt Hole Diameter | 0.660 IN |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536971863 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD180446E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A2927A, 18A2927AC |
| ATE | 424240, SP24240 |
| Autospecialty | EBR1413 |
| BMW | 34119804829, 34119811538 |
| Bosch | 15011600 |
| Carquest | YH322212 |
| Carquest Platinum Painted Rotors | YH322212P |
| Centric Parts | 125.34138 |
| DuraGo | BR901046, BR901046-01 |
| Duralast | 73035DL |
| Dynamic Friction Company | 604-32011, 900-32011, 600-32011 |
| FAG MX | BFR320510 |
| FRITEC | FR03030 |
| HELLA Brakes | 355126291 |
| Mini | 34119804829 |
| NAPA BRAKES | 880967CR, 48880967 |
| PowerStop | EBR1413EVC, EBR1413 |
| Pro-Series | C09569, PS45575 |
| Raybestos Brakes | 980967FZN, 980967R, 980967R2 |
| StopTech | 12534138CRY |
| VAICO | V2080097 |
| Winhere | 6621299, UR003389 |
| Worldparts Synergy | WS1634504 |
WAGNER BD180446E Fits Vehicles
- Mini Cooper Paceman (2013-2016)
- Mini Cooper Countryman (2011-2016)
