CENTRIC 120.44166 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.44166 Specifications
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 13.300 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.050 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 8.307 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 211.000 |
| Discard Thickness | 8.500 MM |
| Discard Thickness | 0.335 IN |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Hat Finish | Painted |
| Overall Height | 62.700 MM |
| Overall Height | 2.469 IN |
| Outside Diameter | 309.000 MM |
| Outside Diameter | 12.165 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 209.000 MM |
| Nominal Drum Diameter | 8.228 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.441 IN |
| Center Hole Diameter | 62.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.567 IN |
| Stud/Lug Hole Diameter | 14.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890580553 |
CENTRIC 120.44166 Cross References
| Brand | Part Number |
|---|---|
| BD180361, 829352706602 | |
| ADVICS | A6R046 |
| N/A | 120.44166, BD180361, BD180361E, E125-49-171, BR90100602, YH289821, 1407-289821, 44691, 31544G, 424310E020, 4243148070, 850191, 880757, 2031544, 90076141, E12549171 |
| NEOTEK | 1063057GF |
| Neotek Premium Drums and Rotors | 1063057GF |
| PRONTO | BR90100602 |
| RAYBESTOS | 980757, 980757FZN, 980757R, 980757R2 |
| Raybestos Brakes | 980757FZN, 980757R, 980757 |
| WAGNER | BD180361, BD180361E |
CENTRIC 120.44166 Fits Vehicles
- Lexus RX450h (2010-2015)
- Lexus RX350 (2010-2015)
- Toyota Highlander (2014-2019)
- Toyota Sienna (2011-2020)
