(888) 312-8812 Login SignupCENTRIC 123.44046 C-Tek Standard Brake Drum
Tap to view 4 more
$7149
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Aug 4
CENTRIC 123.44046 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.44046 Specifications
Product Attributes
| Misc Holes [cntrc] | 8 |
| Weight [cntrc] Kgs | 9.455 |
| Weight [cntrc] Lbs | 20.800 |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 108.000 |
| Hub Hole / Register [cntrc] In | 4.252 |
| Height [cntrc] Mm | 73.700 |
| Height [cntrc] In | 2.902 |
| Friction Surface Width [cntrc] Mm | 61.700 |
| Friction Surface Width [cntrc] In | 2.429 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 306.000 MM |
| Outside Diameter | 12.047 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.400 MM |
| Mounting Hole Diameter | 0.567 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890593553 |
CENTRIC 123.44046 Cross References
CENTRIC 123.44046 Fits Vehicles
- Toyota Tacoma (2005-2023)
CENTRIC 123.44046 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 123.44046 Questions & Answers
No questions yet
Be the first to ask a question about this product!
