(888) 312-8812 Login SignupSTABILUS 4B016990 Liftgate Lift Support
Tap to view 2 more
$2299
Limited availability at this price!
In Stock
Get as soon as Thursday, Sep 24
STABILUS 4B016990 Part Description
Manufacturer
Product Description
Liftgate Lift Support
Features & Benefits
- For best results, replace in pairs.
- Dynamic damping speed control creates a fluid opening motion.
- No bouncing or jerking during cycling.
- Part coatings tested to automotive standards for corrosion resistance.
- Easy to install and require no special tools.
- Based on the OE design to ensure proper fit form and function.
- For best results replace in pairs.
LIFTGATE LIFT SUPPORT
LIFT-O-MAT
STABILUS 4B016990 Specifications
Product Attributes
| NonVehicle Specific | N |
| Transmission Specific | N |
| Engine Specific | N |
| High Performance | N |
| Small Engine | N |
| Marine | N |
| MotorCycleRV | N |
| IndustrialOff Highway | N |
| Personal Watercraft | N |
| Snowmobile | N |
| Agricultural Equipment | N |
| Heavy Truck | N |
| Medium Truck | N |
| CarLight Truck | Y |
| Application Specific | Y |
| Prop 65 Chemical | DEHP |
| Prop 65 Warning | Warning: This product contains a chemical known to the State of California to cause cancer, birth defects or other reproductive harm. |
| Prop 65 Affected | Yes |
| Type | GAS |
| Maximum Force | 390 NW |
| End 2 Mount Diameter | 10.0 MM |
| End 1 Mount Diameter | 10.0 MM |
| Cylinder Outside Diameter | 18 MM |
| Inner Shaft Diameter | 8 MM |
| Compressed Length | 319 MM |
| Extended Length | 540 MM |
| Maximum Force | 88 LB |
| End 2 Mount Diameter | 0.394 IN |
| End 1 Mount Diameter | 0.394 IN |
| Cylinder Outside Diameter | 0.709 IN |
| Inner Shaft Diameter | 0.315 IN |
| Compressed Length | 12.56 IN |
| Extended Length | 21.26 in |
| End 2 Material | Nylon |
| End 2 Type | Ball Socket |
| End 1 Material | Nylon |
| End 1 Type | Ball Socket |
| Mounting Hardware Included | No |
| EXT_NonVehicle Specific | N |
| EXT_Transmission Specific | N |
| EXT_Engine Specific | N |
| EXT_High Performance | N |
| EXT_Small Engine | N |
| EXT_Marine | N |
| EXT_MotorCycleRV | N |
| EXT_IndustrialOff Highway | N |
| EXT_Personal Watercraft | N |
| EXT_Snowmobile | N |
| EXT_Agricultural Equipment | N |
| EXT_Heavy Truck | N |
| EXT_Medium Truck | N |
| EXT_CarLight Truck | Y |
| EXT_Application Specific | Y |
| EXT_Prop 65 Chemical | DEHP |
| EXT_Prop 65 Warning | WARNING: Cancer and Reproductive Harm www.p65warnings.ca.gov |
| EXT_Prop 65 Affected | Yes |
| Stroke Length | 221 MM |
| Stroke Length | 8.7 IN |
Additional Information
| Country of Origin (Primary) | US |
| Country of Origin 2 | MX |
| Country of Origin 3 | DE |
| Harmonized Tariff Code (HTS) | 8302303010 |
| Harmonized Tariff Code (Schedule B) | 8302303010 |
| UPC | 00194879005553 |
STABILUS 4B016990 Cross References
| Brand | Part Number |
|---|---|
| N/A | 016990, BP4K-62-620C, BP4K-62-620D, BP4K-62-620F, BP4K-63-620D, BP4K-63-620F, BP4K62620B, BP4K62620C, BP4K62620D, BP4K62620F, BP4K63620B, BP4K63620C, BP4K63620D, BP4K63620F, 1047VL, 1057VF, 4057VF, 8205TK, 8218TQ, SG227007, TSG227007, 86371, 4B-016990, C96371DL, D96800DL, C96371, D96800, 46371, 6371, 6800, C6371, D6800, 901208, 819-6863, 819-7073, 8196863, 8197073, 612018, 81 554 37, 8155437 |
STABILUS 4B016990 Fits Vehicles
- Mazda 3 (2004-2009)
