REACH COOLING 31-4715 Part Description
Manufacturer
Product Description
A/C Condenser
Application Summary
Ford:2006-2010 Explorer/2007-2010 Explorer Sport Trac; Lincoln:2003-2005 Aviator; Mercury:2006-2010 Mountaineer
Features & Benefits
- All brackets and fittings are made with virgin aluminum to ensure purity of material and strength in brazing bond.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Reach condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
- All our tubes are zinc coated to better handle salt corrosion, especially for areas near the coast or with heavy snow.
- Reach condensers feature a parallel flow design to increase cooling efficiency.
- Tube-and-fin configuration strictly follows OEM design to ensure maximum heat transfer and performance during pressure drop.
- Our tubes feature a 5mm fin height which allows for a greater cooling surface.
- Our condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
- Our condensers feature a parallel flow design to increase cooling efficiency.
No Shipping Restriction
condenser, air conditioning, ac condenser, a/c, cond, parallel flow, accumulator
REACH COOLING 31-4715 Specifications
Product Attributes
| Core Thickness | 18 MM |
| Condenser Core Type | Parallel Flow |
| Mounting Hardware Included | Seals and Gaskets not included |
| Core Length | 21.54 IN |
| Outlet Location | Center Right |
| Core Width | 528 MM |
| Inlet Location | Center Right |
| Includes Drier | No |
| Core Width | 20.79 IN |
| Core Length | 547 MM |
| Core Thickness | 0.71 IN |
| Outlet Diameter | 0.46 IN |
| Outlet Location | Center Right |
| Inlet Diameter | 0.46 IN |
| Outlet Diameter | 11.8 MM |
| Inlet Location | Top Left |
| Core Material | Aluminum |
| Inlet Diameter | 11.8 MM |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 06949521750053 |
REACH COOLING 31-4715 Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 4715 |
| ACDelco | 1563209 |
| APC | 204715 |
| APC Inc | 204715 |
| APDI | 7013588, 7014715 |
| APDI RADS | 7014715 |
| Advance Auto Parts | 1084 |
| American Condenser by Vista-Pro | 1040530, P40530P |
| AutoNation | 6708-00360 |
| AutoZone | 7-4715 |
| Autokool | 3053 |
| CRS | AC4715, AC3588 |
| CSF | 10601 |
| Cancore Industries | 3588 |
| CryoMAX | 0A003588PFYH, 0A004715PFYH, 4715, 3588 |
| DPI DataPoint Inc | 3588, 4715 |
| Dixin USA | DX3588 |
| FVP | CON4715 |
| Factory Air | CON4715 |
| Federated | 4715 |
| Fisher | 7-4715 |
| Ford | 2C5Z19712AA, 4C5Z19712A, 6L2Z19712AA, 8L2Z19712AA, EU2Z19712C, EU2Z19712E, YJ491, YJ521, 2C5H19710AA |
| Four Seasons | 40587 |
| Frontera | 3588AM, 4715AM |
| GLOBAL PARTS DISTRIBUTORS | 3588C |
| Gilmore Products | AUC4715 |
| Global Heat Transfer | 4715 |
| Keystone Auto Industries | CNDDPI3588, CNDDPI4715 |
| Kool Vue | KVAC3588 |
| Koyo | CD321113S |
| Lincoln | 2C5Z19712AA, 2C5H19710AA, 4C5Z19712A |
| Lynol Cooling Systems | AC3588 |
| Mercury | 6L2Z19712AA |
| Motorcraft | YJ443, YJ475, YJ642, YJ644 |
| Murray Heat Transfer | 7-4715 |
| NAPA | 74715, NC4715B |
| NRF | 350248, 8004 |
| Northern Factory Sales | CD82023 |
| Northern Radiator | CD82023, 82023 |
| OEM | 2C5H19710AA |
| OSC | 3588, 4715, 74715 |
| Omega | 24-30444, 2430444 |
| Omega Environmental Technologies | 2430444 |
| PACIFIC BEST INC. | PC4715P, PC3588P |
| PACO | PL3614 |
| PBI | PC4715P |
| Partslink | FO3030201, FO3030221 |
| Performance Radiator | 3533 |
| Platinum Pro | CNDDPI3588 |
| Pro Parts | 350248 |
| Proliance | 640428 |
| RadCool | 4715 |
| Spectra Premium | 7-4715, 74715 |
| Sunbelt Radiators Inc | SBC-3588, SBC-4715 |
| TYG | FD39093A |
| UAC | CN3588PFC, CN4715PFC, CN 3588PFC, CN 4715PFC |
| Valeo | 814153 |
| Vision | 3588P, 4715P |
| Vista Pro | 1084, 640428 |
| XINTIAN | AC37408, AC46608 |
REACH COOLING 31-4715 Fits Vehicles
- Ford Explorer Sport Trac (2007-2010)
- Mercury Mountaineer (2006-2010)
- Ford Explorer (2006-2010)
- Lincoln Aviator (2003-2005)
