(888) 312-8812 Login SignupRAYBESTOS 980194R Raybestos R-Line Brake Rotor
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980194R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2006-2003 Mitsubishi Lancer Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980194R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.544 IN |
| Center Hole Diameter | 90 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.803 IN |
| Discard Thickness | 20.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.495 IN |
| Mounting Bolt Hole Diameter | 12.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 11.81 IN |
| Outside Diameter | 299.95 MM |
| Overall Height | 2.285 IN |
| Overall Height | 58.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213372175 |
RAYBESTOS 980194R Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH145570, YH145570C, YH145570P |
| AutoZone | 31355, 31355DG |
| Autoxtra | AX31355 |
| Bendix | 145570 |
| Bosch | 38011031 |
| BrakeBest | 38011031, 980194, 980194RGS |
| Brembo | 09.7143.31 |
| CENTRIC | 121.46065 |
| Casting Numbers | 211595-C |
| Centric Parts | 120.46065, 121.46065, 125.46065, 125.46065CRY, 126.46065CSL, 126.46065CSR, 126.46065SL, 126.46065SR, 127.46065CL, 127.46065CR, 127.46065L, 127.46065R, 128.46065CL, 128.46065CR, 128.46065L, 128.46065R, 227.46065L, 227.46065R, 320.46065H |
| Dura Corp | BR31355 |
| DuraGo | BR31355 |
| MAGMA PRODUCTS | PMR403010 |
| Mighty Distributing System | 31355 |
| Mitsubishi | 4615A032, MR370724 |
| Newtek Automotive USA | 31355 |
| Promax | 14-31355 |
| Qualis | 31355 |
| Quinton Hazell | BDC5387 |
| UAP | 31355 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51730 |
| WAGNER | BD126126 |
| Wagner Brake | BD126126 |
| Winhere | 4420063 |
RAYBESTOS 980194R Fits Vehicles
- Mitsubishi Lancer (2003-2006)
RAYBESTOS 980194R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 980194R Questions & Answers
No questions yet
Be the first to ask a question about this product!
