NTN WE61548 Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs

★★★★★ (0)
NTN WE61548 Wheel Bearing and Hub Assembly Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
NTN
Tap to view 8 more

$257.99

Limited Availability

Due to limited availability, we will confirm your order and notify you within 1 business day.
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

NTN WE61548 Part Description

Manufacturer

NTN

Product Description

OE form, fit & function wheel hub unit.

Features & Benefits

  • All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
  • Forged-steel construction provides the toughness and durability required for even the harshest applications.
  • Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
  • Application-specific components to ensure proper connection and performance of the ABS module and sensors.
  • Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
  • Application-specific engineering reduces noise, vibration and harshness (NVH).

NTN WE61548 Specifications

Product Attributes

Spline Quantity30
Flange Bolt Hole Quantity3
Wheel Pilot Diameter2.760 IN
Brake Pilot Diameter2.780 IN
Wheel Stud Quantity5
Flange ShapeModified Triangle
Anti Lock Braking SystemYes
Anti Lock Braking System TypeEncoder
Drive TypeDriven
Flange Offset1.656 IN
Bolt Circle Diameter4.528 IN
Knuckle Bolt Circle Diameter (Inches)4.567
Knuckle Bolt Circle Diameter (Millimeters)116.0
Knuckle Bolt Hole SizeM12X1.75
Wheel Stud SizeM12X1.5 MM

Additional Information

Country of Origin (Primary)KR
Harmonized Tariff Code (Schedule B)8708995800
Warranty Time12
Warranty Time UOMMO
UPC662810615487

NTN WE61548 Cross References

BrandPart Number
Alltech Automotive513316
Autopart International1411480970
CENTRIC401.62005
CRS AutomotiveNT513316
Centric Parts401.62005, 401.62005E
DuraGo29513316
GMB7303110
General Motors13580686, 13590795, 13502829, 13583479, 13500572, 13507016, 13526966, 13585466, 13585440
MOOG Chassis Products513316, 513398
MPAWH513316
MevotechH513316
Power TrainPT513316
Raybestos Brakes713316
SKFBR930814, BR930935, BR930954
Schaeffler80598409, 102591, 805984A, 805984.09
TimkenHA590404, HA590572, HA590665, HA590768
WJBWA513316

NTN WE61548 Fits Vehicles

  • Buick Cascada (2016-2019)
  • Buick Encore GX (2020)
  • Buick Envision (2016-2018)
  • Buick LaCrosse (2017-2019)
  • Buick Regal Sportback (2018-2020)
  • Buick Regal TourX (2018-2020)
  • Buick Verano (2012-2017)
  • Cadillac ATS (2013-2019)
  • Cadillac CT4 (2020)
  • Cadillac ELR (2014-2016)
  • Chevrolet Cruze (2014-2015)
  • Chevrolet Malibu (2016-2020)
  • Chevrolet Orlando (2012-2013)
  • Chevrolet Volt (2011-2015)
