(888) 312-8812 Login SignupMAIN FILTER MF0834952 Aftermarket Replacement Hydraulic Filter with 3 Micron Rating, Glass, Outside-In Flow
MSRP: $248.71
$21849
Save $30.22
Limited availability at this price!
In Stock
Get it by Thursday, Jan 15
MAIN FILTER MF0834952 Part Description
Manufacturer
Features & Benefits
- Interchange/replacement for OEM HYDAC/HYCON p/n 01263055
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0834952 replaces OEM 01263055 by HYDAC/HYCON and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Technical Specifications
| Outside Diameter Top | 5.65 |
| Outside Diameter Bottom | 5.65 |
| Inside Diameter Bottom | 3.799 |
| BPVS Setting PSI | 44 |
| Collapse Pressure | 435 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Capacity gr | 176.43154 |
| Filter Area sq in | 2384 |
| Flow Direction | Outside-In |
| Gasket Material | Viton |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 200/3 |
| Beta Ratio 2 | 1000/4.5 |
| Micron 1 | 3 |
Features & Benefits
- Interchange/replacement for OEM HYDAC/HYCON p/n 01263055
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0834952 replaces OEM 01263055 by HYDAC/HYCON and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
- Images may be a general representations of products
MAIN FILTER MF0834952 Specifications
Product Attributes
| Height (in.) | 19.02 |
| Micron Rating | 3 |
| Dust Holding Capacity | 176.43 grams |
| Filter Area (sq. in.) | 2384 |
| Outside Diameter (Top) | 5.65 in. |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| Product Media | Glass |
| Bypass | Yes |
| BPVS Setting (PSI) | 43.5 |
| Fluid Type | HH / HL / HM / HV |
| Wrap | No |
| Beta Ratio 1 | 200/3 |
| Handle | Yes |
| Flow Direction | Outside-In |
| Collapse Pressure | 435 |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Beta Ratio 2 | 1000/4.5 |
| Gasket Material | Viton |
MAIN FILTER MF0834952 Cross References
| Brand | Part Number |
|---|---|
| HYDAC | 01263055 |
