Name: Main Filter MF0223463 Aftermarket Replacement Hydraulic Filter with 10 Micron Rating, Glass, Outside-In Flow
SKU: mf0223463
Price: 108.49 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	3.721
Outside Diameter Bottom	3.721
Inside Diameter Bottom	1.898
BPVS Setting PSI	44
Collapse Pressure	435
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	87.6934355
Filter Area sq in	896
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/9.9
Beta Ratio 2	1000/12.4
Micron 1	10

Features & Benefits

Interchange/replacement for OEM DONALDSON/FBO/DCI p/n P173173
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0223463 replaces OEM P173173 by DONALDSON/FBO/DCI and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Main Filter MF0223463 replaces OEM P173173 by DONALDSON/FBO/DCI and is compatible in fit, form and function.
All of our elements are manufactured following ISO specifications.
Built using Quality Components with strict quality control.
All of our elements are manufactured following ISO specifications.

Features & Benefits

Interchange/replacement for OEM DONALDSON/FBO/DCI p/n P173173
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0223463 replaces OEM P173173 by DONALDSON/FBO/DCI and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Handle	Yes
Wrap	No
Micron Rating	10
Height (in.)	10.82
Bypass	Yes
Product Media	Glass
Outside Diameter (Top)	3.72 in.
BPVS Setting (PSI)	43.5
Collapse Pressure	435
Maximum Operating Temperature	248 Deg Fahrenheit
Minimum Operating Temperature	-13 Deg Fahrenheit
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Filter Area (sq. in.)	896
Dust Holding Capacity	87.69 grams
Beta Ratio 1	200/9.9
Beta Ratio 2	1000/12.4

MAIN FILTER MF0223463 Cross Reference

We have 1 alternatives for the MF0223463 by MAIN FILTER:

DONALDSON P173173
