MAIN FILTER MF0868067 Aftermarket Replacement Hydraulic Filter, 10 Micron Cellulose, Viton Seal, 8.32 in. Height

★★★★★ (0)

MSRP: $33.76

$32.99

Save $0.77

Limited Availability

Due to limited availability, we will confirm your order and notify you within 1 business day.
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

MAIN FILTER MF0868067 Part Description

Manufacturer

MAIN FILTER

Product Description

Aftermarket Replacement Hydraulic Filter, 10 Micron Cellulose, 8.32 in. Height

Features & Benefits

  • Interchange/replacement for OEM LUBER-FINER p/n LH9264V
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0868067 replaces OEM LH9264V by LUBER-FINER and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
Technical Specifications
Outside Diameter Top 2.756
Inide Diameter Top1.595
Outside Diameter Bottom2.756
BPVS Setting PSI25
Collapse Pressure44
Operating Temp Min F-13
Operating Temp Max F248
Capacity gr10.0998
Filter Area sq in253
Flow DirectionOutside-In
Gasket MaterialViton
Fluid TypeHH / HL / HM / HV
Beta Ratio 12/10
Micron 110

MAIN FILTER MF0868067 Specifications

Product Attributes

Product MediaCellulose
Height (in.)8.45
BypassYes
HandleYes
WrapNo
Micron Rating10
Minimum Operating Temperature-13-deg. F
Maximum Operating Temperature248-deg. F
Collapse Pressure44 psi
Outside Diameter (Bottom)2.76 in.
Outside Diameter (Top)2.76 in.
Inside Diameter (Top)1.6 in.
BPVS Setting (PSI)24.7
Gasket MaterialViton
Flow DirectionOutside In
Fluid TypeHL, HM, HV, HH
Beta Ratio 1 2/10
Dust Holding Capacity10.1 grams
Filter Area (sq. in.)253
Capacity10.1g
Bottom Outside Diameter2.756 in.
Filter Rating10 micron
Cracking Pressure44 psi
Filter MediaCellulose
Filter Size253 sq. in.
Flow TypeOutside In
Height8 8/25 in.
Seal TypeViton
Seal MaterialViton
Top Inside Diameter1.595 in.
Top Outside Diameter2.756 in.

MAIN FILTER MF0868067 Cross References

BrandPart Number
LUBER-FINERLH9264V
