Name: Main Filter MF0693596 Aftermarket Replacement Hydraulic Filter with 20 Micron Rating, Glass, Outside-In Flow
SKU: mf0693596
Price: 367.99 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	5.984
Inide Diameter Top	3.284
Outside Diameter Bottom	5.984
Inside Diameter Bottom	3.284
Collapse Pressure	145
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	589.121675
Filter Area sq in	6560
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/20.7
Beta Ratio 2	1000/26.6
Micron 1	25

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF30835
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Images may be general representations of products and may vary from image
Main Filter MF0693596 replaces OEM HF30835 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
Images may be a general representations of products

Features & Benefits

Interchange/replacement for OEM FLEETGUARD p/n HF30835
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0693596 replaces OEM HF30835 by FLEETGUARD and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Product Media	Glass
Handle	No
Bypass	No
Wrap	No
Inside Diameter (Top)	3.29 in.
Maximum Operating Temperature	248 Deg Fahrenheit
Collapse Pressure	145
Dust Holding Capacity	589.12 grams
Gasket Material	Viton
Filter Area (sq. in.)	6560
Minimum Operating Temperature	-13 Deg Fahrenheit
Outside Diameter (Bottom)	5.98 in.
Outside Diameter (Top)	5.98 in.
Micron Rating	20
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/20.7
Inside Diameter (Bottom)	3.29 in.
Flow Direction	Outside-In
Height (in.)	38.58
Beta Ratio 2	1000/26.6

Part Interchanges

Fleetguard HF30835

MAIN FILTER MF0693596 Cross Reference

We have 1 alternatives for the MF0693596 by MAIN FILTER:

FLEETGUARD HF30835
