MPA ELECTRICAL WH515082 Part Description
Manufacturer
Product Description
Wheel Bearing and Hub Assembly
Application Summary
Ford F-250 2009-2005, F-250 Super Duty 2010-2005, F-350 Super Duty 2010-2005
Features & Benefits
- Premium, high-carbon steel alloys improve load bearing capabilities and strength.
- Induction hardened, micro-finished races improve bearing durability and load capacity.
- Application-specific ABS sensors included for perfect vehicle control system signaling.
Wheel Bearing and Hub Assembly
MPA ELECTRICAL WH515082 Specifications
Product Attributes
| Wheel Stud Size MM | M14 x 2.0 |
| Wiring Harness Included | No |
| Greaseable | No |
| Gasket or Seal Included | Yes |
| Spline Quantity | 32 |
| Stud Quantity | 8 |
| Hub Pilot Diameter Inch | 5.51 |
| Product Condition | New |
| Material | Steel |
| Flange Diameter Inch | 7.99 |
| Spline Quantity | 32 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Wheel Studs Included | Yes |
| Flange Shape | Square |
| Anti Lock Braking System Type | Sensor |
| Anti-Lock Brake Sensor Included | Yes |
| Flange Bolt Hole Diameter | 6.5 IN |
| Flange Offset | 1.807 IN |
| Flange Diameter | 7.99 IN |
| Bolt Circle Diameter | 6.695 IN |
| Bolt Circle Diameter | 170.053 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998115 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00029175922832 |
MPA ELECTRICAL WH515082 Cross References
| Brand | Part Number |
|---|---|
| GMB | 7250023 |
| GSP AUTO PARTS NORTH AMERICA INC | 116082 |
| MEVOTECH | H515082 |
| N/A | 19285122, 2HF15082, 5C34-2B513A, 5C34-2B663CG, 5C34-2B663CH, 5C34-2B663CJ, 5C3Z-1104CAA, 6C34-2B513CA, 6C3Z-1104CA, 7C34-2B513CC, 7C3Z-1104C, AC3Z-1104E |
MPA ELECTRICAL WH515082 Fits Vehicles
- Ford F-250 (2005-2009)
- Ford F-250 Super Duty (2005-2010)
- Ford F-350 Super Duty (2005-2010)
