BENDIX K160215SC000 ATC ECU

Name: Bendix K160215SC000 ATC ECU
SKU: k160215sc000
Price: 1458.99 USD
Availability: InStock

★★★★★ (0)

Bendix K160215SC000 ABS Electronic Control Unit ATC ECU

Tap to view 4 more

$1,458.99

+$562.50 core deposit
Total price w/ core: $2,021.49

Limited Availability

Due to limited availability, we will confirm your order and notify you within 1 business day.

30-day Return Policy On eligible items Details

Free Ground shipping on orders over $499 details

BENDIX K160215SC000 Part Description

Manufacturer

BENDIX

Product Description

ATC ECU

Features & Benefits

Combined ABS and traction control logic sits in one controller
Brakes a spinning drive wheel to help maintain forward progress
Smooths launches from icy loading docks or muddy job sites
ATC lamp tells the driver when traction control is actively working

Bendix Automatic Traction Control Electronic Control Unit

Built for trucks working on slick, wet, or loose surfaces, the Bendix Automatic Traction Control Electronic Control Unit combines anti-lock braking with automatic traction control in a single controller. When a drive wheel spins during acceleration, the unit brakes that wheel or limits engine power so the truck can keep moving. Replacing a failed controller with the Bendix K160215SC000 brings those functions back after diagnostic codes have pointed to the ECU itself. Traction support then helps drivers pull away smoothly from icy loading docks and muddy job sites.

BENDIX® ABS ELECTRONIC CONTROL UNIT

Bendix ABS Electronic Control Unit

The Bendix ABS electronic control unit is a critical component in your anti-lock braking system as it is designed to monitor the rotational speed of each wheel. That is why this product is made following the strictest manufacturing processes to ensure the highest level of quality and performance.

Product Type

EC-80 ATC

BENDIX K160215SC000 Specifications

Product Attributes

ABS Modulator Valves	4
CAN Baud Rate	500 Kilobaud
Connector X1	Mates with AMP Connector 1718091-1 (17-Pin / Black)
Connector X2	Mates with AMP Connector 8-968974-1 (18-Pin / Gray)
Connector X3	Mates with AMP Connector 8-968973-1 (15-Pin / Pink)
Connector X4	Not applicable to this part
ECU Replacement Step 1	Use equivalent Bendix ECU to ensure standard default settings.
ECU Replacement Step 2	Not applicable to this part
ECU Replacement Step 3	Not applicable to this part
ECU Type	Automatic Traction Control (Premium)
Input Voltage	12 VDC
Market Indicator	Aftermarket New
Mounting	6.5 MM x 9.5 MM Slot (4x)
Mounting Location	Cab Mount
ROM Version	2
Wheel Speed Sensors	4

Additional Information

Core Class	E7
Core Group	SW
Country of Origin (Primary)	HU
UPC	04068078483220
VMRS Code	013011076
