(888) 312-8812 Login SignupHORTON 79A8138 DM Advantage Two-Speed Reman Fan Clutch
Tap to view 3 more
MSRP: $2,447.22
$1,31199
Save $1,135.23
+$533.33 core deposit
Total price w/ core: $1,845.32
In Stock
Get it by Thursday, Jun 11
HORTON 79A8138 Part Description
Manufacturer
Product Description
DM Advantage Two-Speed Reman Fan Clutch
Application Summary
KENWORTH, PETERBILT
Features & Benefits
- Built to the same specifications as Horton Genuine models
- Easy-to-install, exact drop-in replacements
- Total cost can be less than rebuilding
- Two-year warranty for line-haul applications
- Credit for old Horton or competitor cores
- Low eddy-current speeds reduce noise, increase available horsepower, conserve fuel and minimize radiator abrasion
- Higher, spring-actuated fan speeds make sure necessary cooling is delivered
- Faster engine warm-ups in cold weather
- Premium bearings and friction liners
- High torque for turning large fans
- Lower parts count for easy installation and maintenance
Two-speed fan clutch, fan clutch, engine cooling, fan drive, performance, cooling system, horsepower, performance, reman
HORTON 79A8138 Specifications
Product Attributes
| BACK PULLEY DIAMETER | 6.36 IN |
| BELT CONFIGURATION | 12K |
| Belt Groove Location | 3.39 IN |
| BOLT CIRCLE | 6 IN |
| Center of JB To Top Right Mounting Hole | 2.83 IN |
| Fan Blade Stud Length | 1.1 IN |
| FAN PILOT DIAMETER | 5 IN |
| Heavy Duty | 1 |
| HORIZONTAL MOUNTING DISTANCE | 3.94 IN |
| Overall Length | 9.96 IN |
| Stud Thread Size | .312-18 UNC-2A IN |
| VERTICAL MOUNTING DISTANCE | 3.44 IN |
| Fan Bolt Circle | 6 |
| FRONT PULLEY DIAMETER | - |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483604040 |
| Harmonized Tariff Code (HTS) | 8483604040 |
| NAFTA Preference Criterion Code | B |
| OEM's Part Number | 98A8138 |
| Warranty Distance | 300000 |
| Warranty Distance UOM | DH |
| Warranty Special | 7500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| VMRS Code | 042003131 |
HORTON 79A8138 Cross References
| Brand | Part Number |
|---|---|
| Horton | 98A8138, 99A8138, P99A8138 |
| KIT MASTERS | 99617-2 |
| Kenworth | F17-6018M08 |
| Navistar | HOR79A8138 |
| Paccar Parts | F17-6015M21, 79A8138RMAN |
| Peterbilt | F17-6018M08 |
