(888) 312-8812 Login SignupDELPHI TC5686 Control Arm and Ball Joint Assembly
Tap to view 13 more
$18799
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 18
DELPHI TC5686 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC5686 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Upper |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Machined |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 11.713 IN |
| Control Arm Maximum Width | 297.50 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.984 IN |
| Ball Joint Stud Length | 25.00 MM |
| Control Arm Maximum Length | 11.713 IN |
| Control Arm Maximum Length | 297.50 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | TR |
| UPC | 00689604314364 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
DELPHI TC5686 Cross References
| Brand | Part Number |
|---|---|
| Chrysler | 4895 668AA, 4895 668AB, 5180 596AB, 5180 596AC |
| DORMAN | 521-704, CB81128, CB81128PR |
| Dorman | 52-1704 |
| MAS Industries | CB81128, CB81128PR |
| MEVOTECH | CMS251009, CTXMS251009 |
| MOOG | RK621538 |
| MOOG Chassis Products | RK621538 |
| N/A | CMS251009, GS251009, 622.63829 |
| VAICO | V33-0250 |
DELPHI TC5686 Fits Vehicles
- Dodge Challenger (2017-2019)
- Dodge Charger (2007-2019)
- Chrysler 300 (2005-2019)
- Dodge Magnum (2005-2008)
