CENTRIC 320.67009F - GCX Rotor with Full Coating
$9749
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
GCX Rotor with Full Coating
Application Summary
1985 - 1994 Dodge B150, 1995 - 1997 Dodge B1500, 1985 - 1994 Dodge B250, 1995 - 1997 Dodge B2500, 1985 - 1989 Dodge D100, 1985 - 1993 Dodge D150, 1985 - 1996 Dodge Ramcharger
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
C-Tek; Centric; Standard brake rotor; brake rotor; break rotor; rotors; rotor
Product Attributes
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30.00 MM |
| Nominal Thickness | 1.244 IN |
| Nominal Thickness | 31.60 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.500 IN |
| Outside Diameter | 11.752 IN |
| Outside Diameter | 298.50 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Center Hole Diameter | 3.520 IN |
| Center Hole Diameter | 89.40 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Mounting Bolt Hole Circle Diameter | 139.70 MM |
| Stud/Lug Hole Quantity | 5 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Height | 4.988 |
| Hub Hole/Whl Reg [cntrc] | 89.4 MM |
| Inner Bearing # [cntrc] | 410.91018 |
| Inner Seal # [cntrc] | 417.670 |
| Misc Holes [cntrc] | 5 |
| Outer Bearing # [cntrc] | 410.91016 |
| Solid / Vented | Straight |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] | 13.410 KG |
| Weight [cntrc] | 29.500 LB |
| Disc Mounting | Hub & Rotor |
| Hub Hole Diameter | 89.4 MM |
| Inner Bearing | 410.91018 |
| Inner Seal | 417.670 |
| Misc Holes | 5 |
| Outer Bearing | 410.91016 |
| Vane Style | Straight |
| Weight | 13.410 KG |
| Weight | 29.500 LB |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00889590393620 |
Part Interchanges
CENTRIC 320.67009F Cross Reference
We have 1 alternatives for the 320.67009F by CENTRIC:
Fits Vehicles
- Dodge D150 (1985-1993)
- Dodge B2500 (1995-1997)
- Dodge B250 (1985-1994)
- Dodge B1500 (1995-1997)
- Dodge B150 (1985-1994)
- Dodge D100 (1985-1989)
- Dodge Ramcharger (1985-1996)
